Board Connector, 7 Contact(S), 1 Row(S), Male, Right Angle, 0.156 Inch Pitch, Solder Terminal,
| Application | Power, Wire to-Board |
|---|---|
| Series | 42492 |
| Termination Interface Style | Through Hole |
| Orientation | Right Angle |
| PCB Retention | Yes |
| Glow-Wire Capable | No |
| PCB Locator | Yes |
| Max-Cycle | 1 |
| Plating min - Mating | 5.08 um |
| Flammability | 94 V to 0 |
| Max-Temp | 235 |
| Pitch - Mating Interface | 3.96 mm |
| Lock to Mating Part | Yes |
| PC Tail Length | 3.96 mm |
| CSA | LR19980 |
| Shrouded | Partial |
| Voltage - Maximum | 250 V |
| Component Type | PCB Header |
| Max-Duration | 5 |
| Temperature Range - Operating | See Product Specification |
| Breakaway | No |
| Number of Rows | 1 |
| Current - Maximum per Contact | 7 A |
| Product Name | KK 396 |
| Stackable | Yes |
| Material - Metal | Brass |
| Polarized to Mating Part | Yes |
| Material - Plating Mating | Tin |
| UL | E29179 |
| Durability (mating cycles max) | 25 |
| Circuits (Loaded) | 7 |
| PCB Thickness - Recommended | 1.6 mm |
| Polarized to PCB | Yes |
| Material - Plating Termination | Tin |
| Package Quantity | 1 |
