Board Connector, 8 Contact(S), 1 Row(S), Male, Right Angle, Solder Terminal
| Color | Gray |
|---|---|
| Max. Voltage | 500 V DC |
| Application | Automotive, Power, Signal, Wire-to-Board |
| Series | 34793 |
| Max. Temp. | 105 deg C |
| Terminal Type | Through Hole |
| Material | Alloy |
| Hole Center to Center | 2 mm |
| Number of Rows | 1 |
| Current Rating | 4 A |
| Contact Finish | Tin Plated |
| Terminal Finish | Tin Plated |
| Number of Contacts | 8 |
| Pitch - Mating Interface | 2 mm |
| Polarized to Mating Part | Yes |
| Keying to Mating Part | Yes |
| Product Name | Mini50 |
| PCB Locator | Yes |
| Material - Plating Mating | Tin |
| Temperature Range - Operating | -40° to +105°C |
| PC Tail Length | 2.9 mm |
| Material - Metal | Brass |
| Circuits (Loaded) | 8 |
| Lock to Mating Part | Yes |
| Voltage - Maximum | 14 V |
| Polarized to PCB | Yes |
| First Mate / Last Break | No |
| Material - Resin | Polyester Alloy |
| Orientation | Right Angle |
| Guide to Mating Part | No |
| Material - Plating Termination | Tin |
| Current - Maximum per Contact | 4 A |
| Component Type | PCB Header |
| Breakaway | No |
| Glow-Wire Capable | No |
| Package Quantity | 1 |
