Board Connector, 9 Contact(S), 1 Row(S), Male, Straight, 0.1 Inch Pitch, Surface Mount Terminal,
| Application | Signal, Wire-to-Board |
|---|---|
| Series | 74099 |
| Material - Plating Mating | Tin |
| UL | E29179 |
| Orientation | Vertical |
| Material - Metal | Brass, Phosphor Bronze |
| Plating min - Mating | 3.81 um |
| Color - Resin | Black |
| Material - Plating Termination | Tin |
| Max-Cycle | 3 |
| Termination Interface Style | Surface Mount |
| Product Name | SL |
| Current - Maximum per Contact | 3 A |
| Breakaway | No |
| Pitch - Mating Interface | 2.54 mm |
| Max-Duration | 40 |
| PCB Thickness - Recommended | 1.6 mm |
| Number of Rows | 1 |
| Shrouded | Fully |
| Durability (mating cycles max) | 25 |
| Flammability | 94 V to 0 |
| Glow-Wire Capable | No |
| Material - Resin | High Temperature Thermoplastic |
| Polarized to Mating Part | Yes |
| Temperature Range - Operating | -40° to +105°C |
| Max-Temp | 245 |
| Circuits (Loaded) | 9 |
| Component Type | PCB Header |
| CSA | LR19980 |
| Voltage - Maximum | 250 V |
| Package Quantity | 1 |
