Board Stacking Connector, 5 Contact(S), 1 Row(S), Male, Straight, 0.1 Inch Pitch, Solder Terminal,
| Color | Black |
|---|---|
| Number of Rows | 1 |
| Series | 87937 |
| Max. Voltage | 250 V |
| Application | Board-to-Board, Signal, Wire-to-Board |
| Features | Breakaway; Surface Mount Compatible |
| Hole Center to Center | 2.54 mm |
| Material | Nylon |
| Standards | CSA Certified, UL E29179 |
| Max. Temp. | 265 deg C |
| Terminal Type | Through Hole |
| Terminal Finish | Nickel Plated |
| Number of Contacts | 5 |
| Current Rating | 3 A |
| Flammability Rating | UL 94V-0 |
| Contact Finish | Tin Plated |
| Contact Plating Thickness | 2.54 um |
| Current - Maximum per Contact | 3 A |
| PC Tail Length | 3.76 mm |
| Stackable | No |
| Guide to Mating Part | No |
| Circuits (Loaded) | 5 |
| Polarized to Mating Part | No |
| Material - Plating Termination | Nickel |
| Material - Plating Mating | Tin |
| Material - Resin | Nylon |
| PCB Thickness - Recommended | 1.6 mm |
| Mated Height | 3.78 mm |
| Orientation | Vertical |
| Max-Duration | 14 |
| Pitch - Mating Interface | 2.54 mm |
| Keying to Mating Part | None |
| Breakaway | Yes |
| Glow-Wire Capable | No |
| Max-Temp | 265 |
| Component Type | PCB Header |
| Temperature Range - Operating | -55° to +105°C |
| CSA | LR19880 |
| Product Name | KK 254 |
| Lock to Mating Part | None |
| PCB Locator | No |
| Plating min - Mating | 2.54 um |
| Material - Metal | Alloy |
| Polarized to PCB | No |
| Shrouded | No |
| First Mate / Last Break | No |
| PCB Retention | None |
| Flammability | 94V-0 |
| UL | E29179 |
| Package Quantity | 1 |
