Cable Assembly, 2 Conductor(S), 28Awg, 150V, Flexible Cord And Fixture Wire
| Type | Discrete Wire Assembly |
|---|---|
| Series | 15131 |
| Cable Length | 600 mm |
| Application | Signal, Wire-to-Board |
| Color - Resin | Black |
| Current - Maximum per Contact | 2.5 A |
| Material - Plating Mating | Gold |
| Material - Plating Termination | Tin |
| Wire Insulation Diameter | 0.60mm |
| Gender | Female-Female |
| Wire Size AWG | 28 |
| Circuits (Loaded) | 2 |
| Pitch - Mating Interface | 1 mm |
| Termination Interface: Style | Compression, Crimp |
| Lock to Mating Part | Yes |
| Material - Resin | High Temperature Thermoplastic |
| Number of Rows | 1 |
| Wire/Cable Type | UL 1571 |
| Voltage - Maximum | 150 V |
| Material - Metal | Copper Alloy |
| Single Ended | No |
| Assembly Configuration | Dual Ended Connectors |
| Connector to Connector | Pico-Lock-to-Pico-Lock |
| Product Name | Pico-Lock |
| Overmolded | No |
| Package Quantity | 1 |
