Conector Molex WTB de 8 posiciones con espacio entre pines de 2mm, con capacidad para 2 amperios, montaje en superficie con ángulo recto (RA SMD). Ideal para aplicaciones de conexión en placas electrónicas.
| Polarized to Mating Part | Yes |
|---|---|
| Current - Maximum per Contact | 2 A |
| Orientation | Angle |
| Number of Rows | 1 |
| Voltage - Maximum | 150V AC (RMS)/DC |
| Surface Mount Compatible (SMC) | Yes |
| Material - Metal | Copper Alloy |
| Pitch - Mating Interface | 1.50mm |
| Lock to Mating Part | Yes |
| UL | E29179 |
| Shrouded | Yes |
| Color - Resin | Black |
| Circuits (Loaded) | 8 |
| Plating min - Mating | 0.100µm |
| Temperature Range - Operating | -40 to 105 deg C |
| Termination Interface: Style | Surface Mount |
| Material - Resin | High Temperature Thermoplastic |
| Durability (mating cycles max) | 30 |
| Mated Height | 2.00mm |
| Pitch - Termination Interface | 1.50mm |
| Circuits (maximum) | 8 |
| Material - Plating Mating | Gold |
| Package Quantity | 1 |
