Conector Ffc/Fpc, 5 contactos, 1 fila, hembra, recto, paso de 0.039 pulgadas, terminal de soldadura.
| Item | FFC FPC Connector |
|---|---|
| Color | Natural |
| Max. Voltage | 50V AC/DC |
| Series | 52806 |
| Standards | UL E29179 |
| Material | High Temperature Thermoplastic |
| Features | Surface Mount Compatible |
| Max. Temp. | 80 deg C |
| Hole Center to Center | 1 mm |
| Sub-Category | Connectors |
| Terminal Finish | Tin Plated |
| Contact Plating Thickness | 0.914 µm |
| Current Rating | 0.5 A |
| Number of Contacts | 5 |
| Contact Finish | Tin Plated |
| Number of Rows | 1 |
| Flammability Rating | UL 94V-0 |
| Package Quantity | 1 |
