Conector FFC/FPC, 6 contactos, 1 fila, hembra, paso de 0.1 pulgadas, terminal de crimpado, pestillo, enchufe.
| Color | Black |
|---|---|
| Max. Voltage | 250 V |
| Standards | CSA Certified, UL E29179 |
| Max. Temp. | 105 deg C |
| Hole Center to Center | 2.54 mm |
| Material | Alloy |
| Contact Plating Thickness | 3.81 µm |
| Number of Rows | 1 |
| Current Rating | 1 A, 2 A |
| Number of Contacts | 6 |
| Flammability Rating | UL 94V-0 |
| Contact Finish | Tin Plated |
| Terminal Finish | Tin Plated |
| Package Quantity | 1 |
