Conector Ffc/Fpc, 6 contactos, 1 fila, hembra, paso de 0.1 pulgadas, terminal de engaste, pestillo, enchufe.
| Color | Black |
|---|---|
| Max. Voltage | 250 V |
| Series | 70430 |
| Standards | CSA Certified, UL E29179 |
| Hole Center to Center | 2.54 mm |
| Material | Alloy |
| Max. Temp. | 105 deg C |
| Number of Rows | 1 |
| Flammability Rating | UL 94V-0 |
| Current Rating | 1 A, 2 A |
| Terminal Finish | Tin Plated |
| Contact Finish | Gold Plated |
| Number of Contacts | 6 |
| Contact Plating Thickness | 0.381 µm |
| Stackable | Yes |
| Wire/Cable Type | FFC, FPC |
| Durability (mating cycles max) | 50 |
| Orientation | Vertical |
| Flammability | 94 V to 0 |
| UL | E29179 |
| PCB Retention | None |
| Material - Metal | Phosphor Bronze |
| Material - Resin | Polyester Alloy |
| Material - Plating Mating | Gold |
| PCB Thickness - Recommended | 1.6 mm, 2.4 mm |
| PC Tail Length | 3.3 mm |
| Product Name | SL |
| CSA | LR19880 |
| Material - Plating Termination | Tin |
| Pitch - Mating Interface | 2.54 mm |
| Circuits (Loaded) | 6 |
| Temperature Range - Operating | -40° to +105°C |
| Current - Maximum per Contact | 1 A, 2 A |
| Plating min - Mating | 0.381 um |
| Package Quantity | 1 |
