Conector FFC/FPC, 7 contactos, 1 fila, hembra, recto, paso de 0.039 pulgadas, montaje en superficie.
| Series | 52610 |
|---|---|
| PC Tail Length | 2 mm |
| Material - Plating Mating | Tin-Bismuth |
| Material - Plating Termination | Tin-Bismuth |
| Material - Metal | Phosphor Bronze |
| Circuits (Loaded) | 7 |
| Mated Height | 5.75 mm |
| Stackable | No |
| PCB Mounting | Surface Mount |
| Color - Resin | Natural |
| Polarized to PCB | No |
| PCB Retention | None |
| Current - Maximum per Contact | 1 A |
| PCB Locator | No |
| Durability (mating cycles max) | 30 |
| Wire/Cable Type | FFC, FPC |
| Product Name | Easy-On |
| Voltage - Maximum | 125 V |
| Temperature Range - Operating | -40° to +85°C |
| Material - Resin | Nylon |
| Pitch - Mating Interface | 1 mm |
| Orientation | Vertical |
| CSA | LR19980 |
| Flammability | 94 V to 0 |
| Actuator Type | Slider |
| UL | E29179 |
| Package Quantity | 1 |
