Headers & Wire Housings 1Mm Pico-Lock Crimp Hsg Pos Sidelck 3Ckt
| Color | Black |
|---|---|
| Number of Rows | 1 |
| Series | 503764 |
| Application | Signal, Wire-to-Board |
| Standards | UL E29179 |
| Max. Temp. | 105 deg C |
| Connector Type | Receptacle |
| Material | Thermoplastic |
| Hole Center to Center | 1 mm |
| Flammability Rating | SC-0 |
| Number of Contacts | 3 |
| Temperature Range - Operating | -40° to +105°C |
| Lock to Mating Part | Yes |
| Keying to Mating Part | None |
| Glow-Wire Capable | No |
| Polarized to Mating Part | Yes |
| Pitch - Mating Interface | 1 mm |
| Material - Resin | High Temperature Thermoplastic |
| Circuits (maximum) | 3 |
| Product Name | Pico-Lock |
| UL | E29179 |
| Stackable | No |
| Package Quantity | 1 |
