MGrid Rec SMT VLPR2 /Pg .38AuLF 6Ckt
| Orientation | Vertical |
|---|---|
| Material - Metal | Phosphor Bronze |
| Current - Maximum per Contact | 1 A |
| Lock to Mating Part | Yes |
| Voltage - Maximum | 125 V |
| Max. Cycles at Max. Process Temperature | 1 |
| Flammability | 94V-0 |
| Material - Plating Mating | Gold |
| UL | E29179 |
| Process Temperature max. C | 265 |
| PCB Locator | Yes |
| Circuits (maximum) | 6 |
| Number of Rows | 2 |
| Duration at Max. Process Temperature (seconds) | 14 |
| Material - Resin | High Temperature Thermoplastic |
| Pitch - Mating Interface | 2 mm |
| Termination Interface: Style | Surface Mount |
| Plating min - Mating | 0.381µm |
| Durability (mating cycles max) | 25 |
| Temperature Range - Operating | -55° to +105°C |
| CSA | LR19980 |
| Material - Plating Termination | Tin |
| Plating min - Termination | 1.905µm |
| Circuits (Loaded) | 6 |
| Color - Resin | Black |
| Package Quantity | 1 |
