Pluggable Terminal Blocks 3.81Mm Euro Header R O Header Ra Grn 6Ck
| Pitch - Termination Interface | 3.81 mm |
|---|---|
| Lock to Mating Part | None |
| Stackable | No |
| PCB Thickness - Recommended | 2.5 mm |
| Circuits (Loaded) | 6 |
| UL | E48521 |
| Temperature Range - Operating | -40° to +105°C |
| Polarized to Mating Part | Yes |
| Orientation | Horizontal |
| Panel Mount | No |
| PC Tail Length | 3.5 mm |
| Current - Maximum per Contact | 8 A |
| Pitch - Mating Interface | 3.81 mm |
| Shrouded | Fully |
| Voltage - Maximum | 300 V |
| Number of Rows | 1 |
| Package Quantity | 1 |
