Rectangular Power Connector, 12 Contact(S), Male Or Female, Crimp Terminal, Plug
| Color | Natural |
|---|---|
| Series | 3191 |
| Application | Power, Wire-to-Wire |
| Connector Type | Plug |
| Standards | CSA Certified; UL E29179 |
| Material | Nylon |
| Number of Contacts | 12 |
| Current Rating | 7 A |
| Number of Rows | 3 |
| Max. Temp. | 105 deg C |
| Hole Center to Center | 6.7 mm |
| Flammability Rating | UL 94V-2 |
| Lock to Mating Part | Yes |
| Keying to Mating Part | None |
| UL | E29179 |
| Temperature Range - Operating | -40° to +105°C |
| Current - Maximum per Contact | 7 A |
| Pitch - Mating Interface | 6.7 mm |
| Flammability | 94V-2 |
| Product Name | Standard .093" |
| Glow-Wire Capable | No |
| Stackable | No |
| CSA | LR19980 |
| Material - Resin | Nylon |
| Polarized to Mating Part | Yes |
| Circuits Detail | 3x4 |
| Package Quantity | 1 |
