Iopac 85Xx Communication Module, 4Port Serial, Db44 Connectors
| Operating temperature | -40 to 75°C |
|---|---|
| Database | Telcordia (Bellcore) |
| Baudrate | 300 bps to 921.6 Kbps |
| Stop Bits | 1, 2 |
| Power Consumption | 1.24 W @ 3.3 VDC |
| RS-485-4w | Tx+, Tx-, Rx+, Rx-, GND |
| Interface | 4 RS-232/422/485 ports, software selectable (DB44 male) |
| RS-422 | Tx+, Tx-, Rx+, Rx-, GND |
| Parity | None, Even, Odd |
| Time | 596,611 hrs |
| RS-485-2w | Data+, Data-, GND |
| Data Bits | 7, 8 |
| RS-232 | TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND |
| Flow Control | CTS, RTS, XOFF, XON |
| Connector | DB44 male |
| Package Quantity | 1 |
