Iopac 8600 Power Module, Dual Power Input, 24-110V, 15W
| Input Voltage | 24 to 110 VDC |
|---|---|
| Mounting | DIN Rail, wall, rack |
| EMI | FCC Part 15 Subpart B Class A, CISPR 22 |
| Safety | UL 61010 |
| Operating temperature | -40 to 75°C (-40 to 176°F) |
| Shock | IEC 60068-2-27 |
| Dimensions | 5-slot version: 205.65 x 133.35 x 100 mm (8.1 x 5.25 x 3.94 in); 9-slot version: 324.8 x 133.35 x 100 mm (12.79 x 5.25 x 3.94 in) |
| Rail Traffic | EN 50155 (essential compliance*), EN 50121-3-2, EN 50121-4; *Moxa defines "essential ; compliance" to include those EN 50155 requirements that make products ; more suitable for rolling stock railway applications; Note: Please check Moxa's website for the most up-to-date certification ; status. |
| Storage temperature | -40 to 85°C |
| Altitude | Up to 2,000 m |
| EMS | IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV; IEC 61000-4-3 RS: 80 MHz to 1000 MHz: 3 V/m; 1400 MHz to 2100 MHz: 3 V/m; 2100 MHz to 2700 MHz: 1 V/m; IEC 61000-4-4 EFT: Power: 1 kV; Signal: 0.5 kV; IEC 61000-4-5 Surge: Power: 2 kV (L-PE), 1 kV (L-L |
| Vibration | IEC 60068-2-6 |
| EMC | EN 55022/24 |
| Ambient Relative Humidity | 5 to 95% (non-condensing) |
| Housing | Aluminum |
| Package Quantity | 1 |
