Entrada/Salida Remota Ethernet Inteligente con Click And Go, 12 entradas digitales, 8 salidas digitales, Iologik E2210.
| Mounting | DIN rail or wall |
|---|---|
| Time | 213,673 hrs |
| Over-current Protection | 2.6 A |
| Ambient Relative Humidity | 5 to 95% (non-condensing) |
| Wet Contact (DI to GND) | On: 0 to 3 VDC; Off: 10 to 30 VDC |
| Digital Filtering Time Interval | Software Configurable |
| Safety | UL 508 |
| Protection | 1.5 kV magnetic isolation |
| Interface | RS-485-2w: Data+, Data-, GND (3-contact terminal block) |
| Baudrate | 1,200 to 115,200 bps |
| Protocols | Modbus/TCP, TCP/IP, UDP, DHCP, BOOTP, SNMP, HTTP, CGI, SNTP, SMTP |
| Type | Sink |
| Common Type | 12 points per COM |
| Vibration | IEC 60068-2-6 |
| Power Input | 24 VDC nominal, 12 to 36 VDC |
| Ethernet | 1 10/100 Mbps RJ45 port |
| Digital Outputs | 8 channels |
| Operating temperature | Standard Models: -10 to 60°C (14 to 140°F); Wide Temp. Models: -40 to 75°C (-40 to 167°F) |
| I/O Mode | DO or Pulse Output, DI or Event Counter |
| Over-temperature Shutdown | 175°C (min.) |
| Dry Contact | On: short to GND; Off: open |
| Protocol | RTU, Modbus |
| Altitude | Up to 2,000 m |
| Serial Line Protection | 15 kV ESD for all signals |
| Storage temperature | -40 to 85°C |
| Freefall | IEC 60068-2-32 |
| Power Consumption | 203 mA @ 24 VDC |
| Dimensions | 115 x 79 x 45.6 mm (4.53 x 3.11 x 1.80 in) |
| EMI | EN 61000-3-2; EN 61000-3-3; EN 61000-6-4; FCC Part 15, Subpart B, Class A |
| Data Bits | 8 |
| Isolation | 3k VDC or 2k Vrms |
| Parity | None |
| Pulse Output Frequency | 1 kHz |
| Stop Bits | 1 |
| EMS | EN 61000-4-2, EN 61000-4-3, EN 61000-4-4; EN 61000-4-5, EN 61000-4-6, EN 61000-4-8; EN 61000-4-11, EN 61000-6-2 |
| Over-voltage Protection | 45 VDC |
| Counter Frequency | 900 Hz |
| Sensor Type | Wet Contact (NPN), Dry Contact |
| Digital Inputs | 12 channels |
| Shock | IEC 60068-2-27 |
| Wiring | I/O cable max. 14 AWG |
| Database | Telcordia (Bellcore) |
| Current Rating | 200 mA per channel |
| Package Quantity | 1 |
