Round 16"dia 41"L 30 Degrees SS Wye Branch, 16 in Duct Dia, 304 Stainless Steel, 20 ga GA, 40 in W
| Duct Fitting Duct Size | 16" |
|---|---|
| Width | 40 in |
| For Use With | Industrial Dust Collection |
| Gauge | 20 ga |
| Height | 16 in |
| Construction Material | 304 Stainless Steel |
| Inlet Diameter | 16 in |
| Length | 41 in |
| Outlet Diameter | 16 in |
| Item | 16"dia 41"L 30 Degrees SS Wye Branch |
| Damper Shape | Round |
| Duct Fitting Diameter | 16 in |
| Duct Fitting Item | Branch |
| Duct Fitting Material | Stainless Steel |
| Duct Fitting Length | 41 in |
| Material | Stainless Steel |
| Overall Length | 41 in |
| Series | QF |
| Overall Width | 33 in |
| Overall Height | 41 in |
| Color | Silver |
| End Type | Quick Fit |
| Material Grade | 304 |
| Compatible with Brand | Nordfab |
| Maximum Pressure Rating | 42 in wc |
| Inside Diameter | 16 in |
| Connection Type | Clamp Together |
| Minimum Pressure Rating | 2 in wc |
| Maximum Airflow | Not Applicable |
| Maximum Temperature Rating | 1,100 deg F |
| For Media Type | Dust |
| Product Type | Wye Branch |
| Environment Type | Dusty |
| Angle | 30 deg |
| Shape | Wye |
| For Nominal Duct Diameter | 16 in |
| Weight | 17.56 lb |
| Material Thickness | 20 ga |
| Compatible with Series | Branch |
| Branch Diameter | 16 in |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
