Codo de 30 grados redondo, diámetro de conducto de 12 pulgadas, acero inoxidable 304, calibre 22, 16 1/4 pulgadas de ancho, 16-1/4 pulgadas de largo.
| Duct Fitting Duct Size | 12" |
|---|---|
| Width | 16-1/4 in |
| For Use With | Industrial Dust Collection |
| Gauge | 22 ga |
| Height | 12 in |
| Construction Material | 304 Stainless Steel |
| Inlet Diameter | 12 in |
| Length | 16-1/4 in |
| Outlet Diameter | 12 in |
| Item | 30 Degree Elbow |
| Damper Shape | Round |
| Duct Fitting Diameter | 12 in |
| Duct Fitting Length | 16-1/4 in |
| Duct Fitting Item | 30 Degree Elbow |
| Duct Fitting Material | Stainless Steel |
| Material | Stainless Steel |
| Overall Length | 16-1/4 in |
| Overall Height | 12 in |
| Color | Silver |
| Series | QF |
| Type | 30 Degrees |
| Overall Width | 16-1/4 in |
| Material Thickness | 22 ga |
| Compatible with Brand | Nordfab |
| Maximum Airflow | Not Applicable |
| Inside Diameter | 12 in |
| Number of Pieces | 1 |
| Centerline Radius | 1-1/2 in |
| Maximum Pressure Rating | 42 in wc |
| For Duct Shape | Round |
| Shape | Elbow |
| For Duct Width | 12 in |
| Connection Type | Clamp Together |
| Weight | 12.4 lb |
| For Nominal Duct Diameter | 12 in |
| Angle | 30 deg |
| End Type | Rolled Edge |
| For Duct Height | 12 in |
| Material Grade | 304 |
| Minimum Pressure Rating | 2 in wc |
| Product Type | Elbow |
| Package Quantity | 1 |
