Codo redondo de 45 grados, diámetro de conducto de 16 pulgadas, acero galvanizado, calibre 20, longitud de 26-1/2 pulgadas.
| Duct Fitting Duct Size | 16" |
|---|---|
| For Use With | QF Duct Work |
| Gauge | 22 ga |
| Construction Material | Galvanized Steel |
| Inlet Diameter | 15-63/64 in |
| Length | 26-1/2 in |
| Coating | Galvanized |
| Outlet Diameter | 16 in |
| Pressure Rating | 2 in to 42 in WG |
| Item | 45 Degree Elbow |
| Damper Shape | Round |
| Duct Fitting Diameter | 16 in |
| Duct Fitting Length | 26-1/2 in |
| Duct Fitting Item | 45 Degree Elbow |
| Duct Fitting Material | Galvanized Steel |
| Material | Steel |
| Series | QF |
| Overall Length | 26-1/2 in |
| Type | 45 Degrees |
| Finish | Galvanized |
| Color | Silver |
| Overall Height | 16 in |
| For Duct Shape | Round |
| For Duct Width | 16 in |
| Minimum Pressure Rating | 2 in wc |
| Number of Pieces | 1 |
| Material Thickness | 20 ga |
| Inside Diameter | 16 in |
| For Duct Height | 16 in |
| Centerline Radius | 1-1/2 in |
| End Type | Rolled Edge |
| Shape | Elbow |
| Compatible with Brand | Nordfab |
| Connection Type | Clamp Together |
| Product Type | Elbow |
| Maximum Pressure Rating | 42 in wc |
| Angle | 45 deg |
| Weight | 24 lb |
| Maximum Airflow | Not Applicable |
| For Nominal Duct Diameter | 16 in |
| Package Quantity | 1 |
