Codo redondeado de 45 grados, con diámetro de conducto de 7 pulgadas, fabricado en acero galvanizado calibre 24. Tiene un ancho de 9 pulgadas, una longitud de 9-3/4 pulgadas y una altura de 7 pulgadas.
| Duct Fitting Duct Size | 7" |
|---|---|
| Width | 9 in |
| For Use With | Industrial Dust Collection |
| Gauge | 24 ga |
| Height | 7 in |
| Construction Material | Galvanized Steel |
| Inlet Diameter | 7 in |
| Length | 9-3/4 in |
| Coating | Galvanized |
| Outlet Diameter | 7 in |
| Item | 45 Degree Elbow |
| Damper Shape | Round |
| Duct Fitting Diameter | 7 in |
| Duct Fitting Length | 9-3/4 in |
| Duct Fitting Material | Galvanized Steel |
| Duct Fitting Item | 45 Degree Elbow |
| Material | Steel |
| Finish | Galvanized |
| Color | Silver |
| Type | 45 Degrees |
| Overall Height | 7 in |
| Overall Length | 9-3/4 in |
| Series | QF |
| Overall Width | 9 in |
| Number of Pieces | 1 |
| For Duct Height | 7 in |
| Minimum Pressure Rating | 2 in wc |
| End Type | Rolled Edge |
| Inside Diameter | 7 in |
| Connection Type | Clamp Together |
| Maximum Airflow | Not Applicable |
| Compatible with Brand | Nordfab |
| Shape | Elbow |
| For Nominal Duct Diameter | 7 in |
| Angle | 45 deg |
| Centerline Radius | 1 in |
| Product Type | Elbow |
| Weight | 2.2 lb |
| Maximum Pressure Rating | 42 in wc |
| For Duct Shape | Round |
| Material Thickness | 24 ga |
| For Duct Width | 7 in |
| Package Quantity | 1 |
