Interruptor de presión Serie 300, SPDT, 15-230 psi, cable integrado de 3 pies.
| Item | Mechanical Switch |
|---|---|
| Pressure Switch Application | Hydraulics and Pneumatics, Pumps and Compressors, Tank Monitoring, Leak Detection, Water Management |
| Pressure Switch Factory On/Off Setting | Field Adjustable and/or Factory Set |
| Pressure Switch Electrical Contact Form | Single Pole Double Throw |
| Pressure Switch Action | Snap with Adjustable Hysteresis |
| Wetted Materials | NBR |
| Process Connection | 1/4" NPT |
| Media Temp. Range | -4 to 176 deg F |
| Housing Material | Steel |
| Electrical Connection | 3 ft Integral Cable |
| AC Contact Rating | 6 A |
| IP Rating | IP67 |
| DC Contact Rating | 6 A |
| Ambient Temp. Range | -4 to 176 deg F |
| Series | 300 |
| Max. Pressure | 870 to 5000 psig |
| Package Quantity | 1 |
