Relé de propósito general, 120V AC Voltios de bobina, Cuadrado, 14 pines, 4PDT.
| Item - Relay | General Purpose Relay |
|---|---|
| Coil Volts | 120V AC |
| AC Contact Rating - Relay | 10A @ 120V |
| DC Contact Rating - Relay | 10 A @ 24 V |
| Base Type - Plug In Relay | Square |
| Number of Pins - Relay | 14 |
| Contact Form - Relay | 4PDT |
| Mounting - Relay | Plug In |
| HP @ 120V | 1/10 hp |
| Base Type | Square |
| Overall Height - Relay | 1.69 in |
| Socket | Mfr. No. PTF14A |
| Socket Code | F |
| Body Width - Relay | 1.63 in |
| Features | Arc Barrier Equipped, High Dielectric Strength (2000V AC), Long Dependable Service Life Assured By Ag-Alloy Contacts |
| Contact Material | Silver Alloy |
| Item | General Purpose Relay |
| Body Height - Relay | 1.42 in |
| Green Environmental Attribute | RoHS 2011/65/EU Compliant |
| HP @ 240V | 1/3 hp |
| Body Depth - Relay | 1.1 in |
| Pins | 14 |
| Standards | CE Certified, CSA Certified, TUV Certified, UL Listed |
| Contact Rating | 10A @ 120VAC/24VDC |
| Status Indicator | None |
| Power Consumption - Relay | 2 VA |
| Push To Test | Manual |
| Contact Form | 4PDT |
| Overall Depth | 1.67 in |
| Sealing | Enclosed |
| Maximum Switching Voltage | 125 V DC, 250 V AC |
| Input Voltage | 120 V AC |
| Series | LY Series |
| Coil Resistance | 4,430 ohms |
| Coil Voltage | 120 V AC |
| Push-To-Test Method | Manual |
| Base Shape | Square |
| Compatible with Manufacturer Model Number | PT14, PT14-0, PT14QN, PTF14A, PTF14A-E |
| Flat Pin Width | 0.197 in |
| Response Time | 25 msec |
| Horsepower @ 240V AC | 0.3333 HP |
| Horsepower @ 120V AC | 1/10 hp |
| Pin Shape | Flat |
| Insulation Resistance | 100 megaohm |
| Body Width | 1.63 in |
| Mounting Style | Plug-In |
| Number of Pins | 14 |
| Contact Rating (AC) | 10 A @ 120V, 7.5 A @ 120V |
| Power Consumption | 0.53 W |
| Motor Rated | Yes |
| Electrical Connection | Quick-Connect |
| Contact Rating (DC) | 10 A @ 24 V |
| Minimum Operating Temperature | -13 deg F |
| Mechanical Operating Durability | 500,000,000 |
| Dielectric Strength | 10,000V AC Between Contacts of Same Polarity, 2,000V AC |
| Electrical Operating Durability | 200,000 |
| Body Depth | 1.42 in |
| Weight | 2.47 oz |
| Current Rating | 10 A |
| Maximum Operating Temperature | 104 deg F |
| Body Height | 1.1 in |
| Package Quantity | 1 |
