Cabezal giratorio de interruptor de límite Nema 3, 4, 4X, 6P, 12, 13
| Item | Limit Switch Head |
|---|---|
| Actuator Style | Roller Lever Plunger |
| Actuator Location | Side |
| Contact Form | Not Specified |
| For Use With | Mfr. No. D4A1102N |
| NEMA Rating | 12, 13, 3, 4, 4X, 6P |
| Movement | Side |
| Travel | Not Specified |
| Amps | Not Specified |
| Standards | CSA, UL Listed |
| Voltage Rating | Not Specified |
| Operating Force | Not Specified |
| IP Rating | IP67 |
| Description/Special Features | High-Sensitivity |
| Operating Temp. | -40 to 212 deg F |
| Roller Material | Not Applicable |
| Features | High Sensitivity |
| Differential Travel | 3 Degrees |
| Series | D4A |
| Arm Width | Not Applicable |
| Roller Width | Not Applicable |
| Arm Material | Steel |
| Arm Depth | 0.57 in |
| Arm Length - Minimum | Not Applicable |
| Directional Movement | Linear |
| Reset Travel | Not Applicable |
| Arm Length - Maximum | Not Applicable |
| Arm Adjustability | Fixed |
| Overtravel | 75 Degrees |
| Compatible with Manufacturer Model Number | D4A1102N |
| Operating Temperature - Maximum | 212 deg F |
| Operating Temperature - Minimum | -40 deg F |
| Compatible with Series | D4A |
| NEMA Enclosure Rating | 1, 12, 13, 2, 3, 4X, 5, 6P |
| Roller Adjustability | Not Applicable |
| Action | Maintained |
| Total Travel | Not Applicable |
| Operating Torque | 3.45 in-lb |
| Roller Position | Not Applicable |
| Pretravel | Not Applicable |
| Roller Diameter | Not Applicable |
| Plunger Adjustability | Fixed |
| Compatible Manufacturer Part Number | D4A1102N |
| Compatible Manufacturer Model Number | D4A1102N |
| Package Quantity | 1 |
