Power Supply, 100/240V AC, 24V DC, 60W, 2.5A, DIN Rail
| Item | Power Supply |
|---|---|
| Input Voltage | 100/240V AC |
| Output Voltage | 24V DC |
| Power Rating | 60 W |
| Output Amps | 2.5 A |
| Mounting | DIN Rail |
| Phase - Electrical | Single |
| Style | Switching |
| Height | 94.7 mm |
| Width | 55 mm |
| Depth | 92.3 mm |
| Hz | 50/60 Hz |
| Standards | EN/IEC 60529 |
| IP Rating | IP20 |
| Features | Power Boost Function at 150% (240 and 480 W), Product Replacement Time, Output Voltage, Output Current, and More are Acquired on the Network and can be Managed all at Once, Product Status can be Checked On-Site Using the Indication Monitor, Side-By-Side Mounting Possible (upto 55 Degrees C), UL Class 2 Conformance (90 W or Less) |
| Operating Temp. Range | -40 to 70 deg C |
| Status Indicator | Green (Output), Red (Alarm) |
| Series | S8VK-X |
| Hold Up Time | 110 msec @ 230 V AC, 20 msec @ 115 V AC |
| Peak Amps | 3 A |
| Output Noise | 110 mV @ 20 MHz |
| Maximum Efficiency @ 230V AC | 86% |
| Operating Temperature - Maximum | 158 deg F |
| Start Up Time - Maximum | 1,000 msec |
| Current - Peak | 3 A |
| Operating Temperature - Minimum | -40 deg F |
| Manufacturer Warranty | 5 yr |
| Wire Size - Minimum | 20 AWG |
| Current - Output | 2.5 A |
| Wire Size - Maximum | 14 AWG |
| Maximum Efficiency @ 115V AC | 85% |
| Special Features | Alarm Indication, LED Diagnostic Indicators, Overload Protection, Overvoltage Protection, Parallel Capability, Series Operation |
| Current - Inrush | 32 A |
| Wire Connection Type | Push In |
| Input Frequency - Nominal | 50/60 Hz |
| Mean Time Between Failures (MTBF) | 160,000 hr |
| Output Power - Rated | 60 W |
| Package Quantity | 1 |
