Relé de estado sólido, entrada de 100-120VCA, salida de 200-480VCA.
| Item - Relay | Solid State Relay |
|---|---|
| Input or Control Voltage | 100 to 120 V AC |
| Output or Controlled Voltage Range | 200 to 480 V AC |
| Max. Output Amps w/Heat Sink | 20 A |
| Heat Sink | Not Included |
| Switch Type | SCR |
| Contact Form - Relay | SPST-NO |
| Relay Turns On At | Zero Crossing |
| Input Power Consumption (Burden) | 0.8 VA |
| Mounting - Relay | Surface |
| Input Voltage | 100 to 120V AC |
| Item | Solid State Relay |
| Finger Safe | Yes |
| Standards | CSA Certified, EN (TUV), UL Listed |
| Switch Component Type | Photocoupler |
| Dielectric Strength | 4,000V AC |
| Current Type | AC |
| Drop Out Voltage | 1.8 V DC |
| Electrical Phase | Single |
| Voltage Type | AC Output |
| Input Current | 20 A |
| Output Voltage Range | 200 to 480 V AC |
| Maximum Output Current with Heat Sink | 20 A |
| Weight | 2.82 oz |
| Series | G3NA Series |
| Maximum Operating Temperature | 176 deg F |
| Body Height | 2.28 in |
| Overall Depth | 1.18 in |
| Insulation Resistance | 100 megaohm |
| Maximum Output Current without Heat Sink | 20 A |
| Frequency | 50/60 Hz |
| Mounting Style | Screw |
| Electrical Connection | Screw Clamp |
| Minimum Operating Temperature | -22 deg F |
| Output Switching Mode | Zero Crossing |
| Switch Configuration | Form A |
| Body Depth | 1.1 in |
| Body Width | 1.69 in |
| Package Quantity | 1 |
