Thread Forming Tap, 7/16"-14, Modified Bottoming, TiCN, 0 Flutes
| Item | Thread Forming Tap |
|---|---|
| Tap Thread Size | 7/16"-14 |
| Tap Chamfer | Modified Bottoming |
| Tap Finish | TiCN |
| Number of Flutes | 0 |
| Tap Style | Thread Forming |
| Pitch Diameter Limit | H8 |
| List Number | 16250 |
| Thread Length | 1-7/16 in |
| Overall Length | 3-15/16 in |
| Shank Dia. | 0.242 in |
| Tap Dimension Type | Inch |
| Tap Grouping | Tap |
| Number of Pieces | 1 |
| Tap Material | Cobalt |
| Tap Size | 7/16" |
| Thread Direction | Right Hand |
| Tap Thread Type | UNC |
| Standards | DIN |
| Cutting Direction - Machining | Right Hand |
| Series | 16250 |
| Primary Material Application | Brass, Copper, Bronze, Aluminum, Hardened Steel, Stainless Steel, Steel |
| 65% Thread Drill Size | 10.3 mm |
| Secondary Material Application | Titanium, Nickel, Hardened Steel |
| Tap Length Standard | DIN |
| Material Grade - Machining | 16250 |
| Coolant Fed | Non-Coolant Through |
| Spiral Direction | Neutral |
| Extended Neck | Yes |
| Thread Size | 7/16"-14 |
| Class of Fit | 2B |
| Features | Produces No Chips |
| 75% Thread Drill Size | 10.2 mm |
| Secondary Material Application ISO Code | H, S |
| 55% Thread Drill Size | 10.4 mm |
| Shank Length | 2-7/32 in |
| Square Size | 0.242 in |
| Thread Limit | H8 |
| Thread Standard | UNC |
| Threads per Inch | 14 |
| Primary Material Application ISO Code | P, N, M, H |
| Tap Shank Standard | ANSI |
| Helix Angle | 0 Degrees |
| Package Quantity | 1 |
