Cyclone 200ES it's a good MIG welder with 200A capability and a 25% duty cycle at 180A. This new MIG model now features stick welding capability for a more complete welder package. With 160A stick output, the unit is capable of using up to a 1/8" welding rod, more than enough for your average stick welding needs. And if stick won't do, the unit also features a Flux-Cored mode for those times when the wind is too much for MIG.The PowerSet function helps you to get up and running quickly, without having to refer to complicated charts or calculators. Simply enter the basic parameters of what you are working with, and the unit will automatically set the output for you. If you don't need or want the setup assistance that PowerSet provides, the manual mode is always available. In PowerSet mode, you have settings for MIG with 75/25 Ar/CO2, MIG with 100% CO2 and Flux-Cored (gasless) wire. If you need to weld Aluminum, it can be used in manual mode.The Cyclone 200ES has a display that is clear and bright. The settings are easily visible at a distance, even in bright sunlight or lighting conditions.Even though the Cyclone 200ES is very compact and lightweight, the unit still allows the use of up to 8" rolls that weigh up to 12 lbs. Of course, you can use 4" rolls as well, or if you prefer, you can purchase a spool gun to use those in as well, especially for Aluminum applications (Aluminum for use with Manual mode only).
| Duty Cycle (%) | 35 |
|---|---|
| Engine Power | Electric (AC) |
| Included | Kit |
| Input Power (Volts) | 220 |
| Material Application Thickness (in.) | 1 |
| Maximum amperage output (amps) | 200 |
| Minimum amperage output (amps) | 30 |
| Process Application Type | MIG (GMAW) |
| Rated Output (Volts) | 24 |
| Returnable | 90-Day |
| Welder Type | MIG,Wire-Feed |
| Manufacturer Warranty | 5 year warranty |
| Product Depth (in.) | 17 in |
| Product Height (in.) | 14 in |
| Product Width (in.) | 8 in |
