Hydraulic system is protected from internal damage by a patented by-pass mechanism. Machined and polished cylinders with die-cut threads provide non-abrasive leak-free, durable performance. Fabricated from hard-cast steel with heat-treated critical stress areas. Serrated heat-treated saddle provides generous lifting area and secure grip. Heat-treated extension screw allows low pick-up height adjustment and maximum lift height U.S. Patented built-in by-pass device protects hydraulic system from over pumping damage. Unique cross-type forged release valve assures positive control. A wide, rugged base provides stability and strength. Critical stress points are reinforced in all models for added durability and dependability.
| Features | No Additional Features |
|---|---|
| Frame Material | Steel |
| General Part Type | Bottle Jack |
| Included | Handle |
| Material | Steel |
| Maximum Lift Height (in.) | 14.25 in |
| Mechanism type | Hydraulic |
| Minimum Lift Height (in.) | 7.5 |
| Product Weight (lb.) | 6.33 lb |
| Returnable | 90-Day |
| Saddle Diameter (in.) | 1 |
| Weight Capacity (lb.) | 8000 lb |
| Manufacturer Warranty | One Year |
| Base Length (in.) | 3.9 |
| Base Width (in.) | 4.15 |
| Collapsed height (in.) | 6.75 |
| Handle Length (in.) | 6.25 in |
| Product Depth (in.) | 5 in |
| Product Height (in.) | 8 in |
| Product Width (in.) | 4 in |
