Siemens General Duty Safety Switches are intended for applications where reliable performance and continuity of service are needed, but where duty requirements are not severe and usual service conditions prevail. These switches are intended for use primarily with supply circuits rated 240-Volt AC or less where the available fault current is less than 100,000A when used with Class R or T fuses or 10,000A maximum when used with Class H fuses. All switches are provided with imbedded ON and OFF indicators and padlocking provisions on the handle and door. All switches are UL Listed. Fuses not included on fusible device.
| Automatic/Manual | Manual |
|---|---|
| Disconnect Type | Safety Switch |
| Electrical Product Type | Safety Switch |
| Features | Mountable,On/Off Switch |
| Fused | Fused |
| Indoor/Outdoor | Outdoor |
| Maximum Amperage (A) | 30 A |
| Maximum Wattage (W) | 0 W |
| NEMA Configuration | NEMA 3R |
| Phase Type | 1 Phase |
| Power Distribution Features | Fusible |
| Product Weight (lb.) | 3 lb |
| Returnable | 90-Day |
| Type | Safety Switch |
| Voltage (V) | 240 V |
| Certifications and Listings | UL Listed |
| Manufacturer Warranty | Standard Limited Warranty |
| Product Depth (in.) | 2.75 in |
| Product Height (in.) | 8.56 in |
| Product Width (in.) | 5.44 in |
