Draft Inducer, 115, Metal, 11 1/4 in W, 7 in H
| Item | Draft Inducer |
|---|---|
| Voltage | 115 V |
| Depth (In.) | 11-1/4 |
| Construction Material | Metal |
| Amps | 0.53 |
| Remarks | Product Used as Direct OEM Replacement Only. Any Other use Constitutes a Misapplication, Which Voids the Warranty and May Create Unsafe Conditions |
| Height (In.) | 7 |
| Vent Pipe Dia. (In.) | 3.3 |
| For Use With Mfr. Model Number | 117521-00, 40404-003 |
| Fits Brand | Armstrong |
| Replaces | Fasco 7021-12439, Armstrong 117521, Armstrong 117521-00, Armstrong 40404-003, Armstrong 40404-3, Ametek 117521, Ametek 117521-00 |
| Agency Compliance | CSA, UL |
| Width (In.) | 11-1/4 |
| Application | Furnaces |
| Number of Speeds | 1 |
| RPM | 3,300 |
| Bearings | Ball |
| Enclosure | Open |
| Frame | 3.3 |
| Class | B |
| Overload Protection | Automatic |
| Motor Type | Permanent Split Capacitor |
| Phase | 1 |
| Includes Mounting Hardware | Yes |
| Maximum Motor Speed | 3,300 rpm |
| Overall Depth | 11-1/4 in |
| Housing Material | Plastic |
| Includes Motor | Yes |
| Maximum Inlet Air Temperature | 40 deg C |
| Motor Insulation Class | B |
| Maximum Static Pressure | 0.125 in wc |
| For Appliance Type | Furnaces |
| Compatible with Brand | Ametek, Armstrong, Fasco, Nidec, US Motors |
| For Fuel Type | Natural Gas |
| Current | 0.53 A |
| For Use With | 117521-00, 40404-003, Armstrong |
| Overall Width | 11-1/4 in |
| Nameplate Voltage | 115V AC |
| Standards | UL Listed, CSA Certified |
| Maximum Motor Horsepower | 1/30 hp |
| OEM Replacement | Yes |
| Replacement For Manufacturer Model Number | 117521, 117521-00, 40404-003, 40404-3, 7021-12439, N180 |
| Overall Height | 5-7/8 in |
| Frequency | 60 Hz |
| Blower Type | Induced Draft Furnace Blower |
| Country of Origin (subject to change) | Taiwan, Province of China |
| Package Quantity | 1 |
