Terminal de horquilla no aislado de 18-14 AWG para tornillo #8, paquete de 100 unidades.
| Wire Range | 18 to 14 AWG |
|---|---|
| Insulation Type | Non-Insulated |
| Stud Size | #8 |
| Insulation Color | Bare |
| Seam | Brazed |
| Connection Type | Crimp |
| Max. Temp. | 302 deg F |
| Features | Barrel of Terminal Internally Beveled to Provide, Fork Design Provides for Fast and Easy Installation, Internal Barrel Serrations Assure Good Wire Contact and Maximum Tensile Strength, Without The Need to Remove Fastener |
| Terminal Connection | Crimp |
| Max. Voltage | 2,000 V |
| Item | Fork Terminal |
| Standards | UL 587-H, UL Listed |
| Terminal Type | Standard |
| Connection Material | Copper |
| Overall Length | 0.69 in |
| Tongue Width - Wire Connector | 0.31 in |
| Terminal Shape | Fork |
| Insulation Material | None |
| Barrel Length | 0.27 in |
| Tongue Length | 0.00 - 0.50 inches |
| Compatible with Series | CT |
| Tongue Thickness | 0.03 in |
| Compatible with Product Type | Crimper, Crimp Tool, Wire Stripper |
| Contact Finish | Tin |
| Maximum Operating Temperature | 302 deg F |
| Maximum Wire Size | 14 AWG |
| Compatible Manufacturer Model Number | CT-100A, CT-1570, CT-160, CT-1701 (P10), CT-200, CT-2500 (CT-2570CH), CT-260, CT-600-A (CT-570CH) |
| Seam Style | Brazed |
| Tongue Width | 0.31 in |
| Special Features | Barrel of Terminal Internally Beveled to Provide, Fork Design Provides for Fast and Easy Installation, Internal Barrel Serrations Assure Good Wire Contact and Maximum Tensile Strength |
| Maximum Voltage | 2,000 V |
| Strip Length | 1/4 in |
| Contact Material | Copper |
| Termination Style | Crimp |
| Insulation Coverage | None |
| Minimum Wire Size | 18 AWG |
| Package Quantity | 100 |
