Cable Tie, Mnt, Wingedpsh Mnt, Wr, Bl, PK1000
| Item | Cable Tie,Mnt,Wingedpsh Mnt,Wr,Bl,PK1000 |
|---|---|
| Color | Black |
| Material | Weather Resistant Nylon 6.6 |
| For Use With | Miniature, Intermediate, Standard Cross-Section Ties |
| Application | Push Barb Cable Tie Mounts Wing Provides Added Stability and Can be Used where Only One Side of the Panel is Accessible |
| Overall Length | 0.71 in |
| Depth | 3/4 in |
| Width | 0.37 in |
| Height | 0.61 in |
| Overall Length (mm) | 18 |
| Maximum Operating Temperature (°F) | 185 |
| Minimum Operating Temperature (°C) | -60 |
| Mount Method | Push Barb |
| Minimum Operating Temperature (°F) | -76 |
| Maximum Operating Temperature (°C) | 85 |
| Product Type | Cable Tie Mount |
| Overall Height (mm) | 15.7 |
| Maximum Compatible Panel Thickness (mm) | 2.8 |
| Maximum Compatible Panel Thickness (In.) | 0.11 |
| Overall Height (In.) | 0.62 |
| Overall Length (In.) | 0.71 |
| Overall Width (In.) | 0.37 |
| Resistance Properties | UV Resistant |
| Environment | Indoor, Outdoor |
| Overall Width (mm) | 9.3 |
| Product Material | Nylon |
| Additional Information | Environment: Indoors/Outdoors |
| Product Color | Black |
| Cable Manager Type | Cable Tie Mount |
| Product Line | Push Barb |
| Product Name | Winged Push Barb Cable Tie Mount |
| Product Class | Cable & Wire Ties, Mounts & Straps |
| Min Operating Temperature | -60 degrees celsius |
| Max Operating Temperature | 85 degrees celsius |
| Package Quantity | 1000 |
