Cable Tie, Mount, Adh, .75"x.75", Wht, PK100
| Item | Cable Tie Mounting Base |
|---|---|
| Size | 0.75 in L x 0.75 in W x 0.18 in H |
| Color | White |
| Material | ABS |
| Temp. Range | -20 to 120 deg F |
| Standards | CE Compliant, RoHS Compliant, UL E136577 |
| Mounting Method | Adhesive Mount |
| Clip Type | Four-Way |
| Width | 3/4 in |
| Height | 0.18 in |
| Length | 3/4 in |
| Flame Retardant | No |
| Number of Entries | 4 |
| Slot Width | 0.17 in |
| Max. Temp. Rating | 120 deg F |
| Min. Temp. Rating | -20 deg F |
| Slot Height | 0.07 in |
| Metal Detectable | No |
| For Use With | Miniature and Intermediate Cable Ties |
| Length (Straight Wireway) | 3/4 in |
| Static Load Capacity (lb) | 0.3 |
| Overall Length (mm) | 19.1 |
| Overall Width (In.) | 3/4 |
| Maximum Operating Temperature (°F) | 120 |
| Overall Width (mm) | 19.1 |
| Product Type | Cable Tie Mount |
| Static Load Capacity (kg) | 0.136 |
| Overall Length (In.) | 3/4 |
| Maximum Compatible Panel Thickness (In.) | 0.04 |
| Minimum Operating Temperature (°F) | -20 |
| Overall Height (mm) | 4.6 |
| Maximum Operating Temperature (°C) | 49 |
| Maximum Compatible Panel Thickness (mm) | 1 |
| Environment | Indoor |
| Minimum Operating Temperature (°C) | -29 |
| Overall Height (In.) | 0.18 |
| Mount Method | Rubber Adhesive Tape |
| Additional Information | Environment: Indoors |
| Depth | 3/4 in |
| Cable Manager Type | Cable Tie Mount |
| Product Material | Acrylonitrile Butadiene Styrene |
| Product Name | 4-Way Adhesive Backed Cable Tie Mounts |
| Product Color | White |
| Standards Met | CE Compliant, UL Recognized: E136577, RoHS Compliant |
| Minimum Operating Temperature (°F) | -20 |
| Maximum Operating Temperature (°C) | 49 |
| Minimum Operating Temperature (°C) | -29 |
| Maximum Operating Temperature (°F) | 120 |
| Package Quantity | 100 |
