Compression Connector, 6AWG-250Kcmil
| Item | Compression Connector,6AWG-250Kcmil |
|---|---|
| Overall Length | 2.01 in |
| Features | Halogen Free |
| Application | Stranded Aluminum or Copper Code Conductor |
| Product Type | Mechanical Connectors, Hole, Single Barrel - Lugs |
| Maximum Voltage (V) | 600 |
| Hex Size (mm) | 7.9 |
| Overall Length (mm) | 50.5 |
| Tongue Angle | Straight |
| Overall Length (In.) | 1.99 |
| Overall Height (In.) | 1.1 |
| Overall Width (In.) | 0.99 |
| Maximum Aluminum Conductor Size (kcmil) | 250 |
| Stud Hole Size (In.) | 45,062 |
| Tongue Thickness (mm) | 6.3 |
| Tongue Length (mm) | 25.1 |
| Tongue Length (In.) | 0.99 |
| Tongue Width (In.) | 0.99 |
| Overall Width (mm) | 25.1 |
| Number of Holes | 1 |
| Tongue Width (mm) | 25.1 |
| Minimum Copper Conductor Size (AWG STR) | 6 |
| Finish/Coating | Tin-Plated |
| Barrel Type | Single Barrel |
| Wire Strip Length (mm) | 25.4 |
| Hex Size (In.) | 45,062 |
| Barrel Length (In.) | 1 |
| Barrel Length (mm) | 25.4 |
| Maximum Copper Conductor Size (kcmil) | 250 |
| Standards Met | cULus Listed for use up to 600V & Temperature Rated to 90°C |
| Tongue Type | Straight Tongue |
| Minimum Aluminum Conductor Size (AWG) | 6 |
| Tongue Thickness (In.) | 0.25 |
| Base Material | Aluminum |
| Wire Strip Length (In.) | 1 |
| Overall Height (mm) | 27.9 |
| UL Temperature Rating (°C) | 90 |
| Product Name | Terminal Connector |
| Connector Details | 1 x Barrel Plug |
| Connector Plating | Tin |
| Product Material | Copper, Aluminum |
| Product Class | Lugs, Splices, Mechanical |
| Package Quantity | 1 |
