Terminal de Compresión de Cobre, 1 Orificio, 500 Kcmi
| Material | Copper |
|---|---|
| Color Code | Pink |
| Barrel Length | 2.88 |
| Overall Length | 5.03 in |
| Hole Center to Center | 44563 |
| Tool Type | Tin-Plated Copper Compression Connectors - Lugs |
| Tongue Thickness (In.) | 0.26 |
| DLO Copper Flex Conductor Size (kcmil) | 535.3 |
| Wire Strip Length (mm) | 75 |
| Burndy Die Index Number | L99 |
| Maximum Voltage (kV) | 35 |
| Barrel Length (mm) | 73.2 |
| Class M Copper Flex Conductor Size (kcmil) | 500 |
| Overall Length (mm) | 127.8 |
| Class K Copper Flex Conductor Size (kcmil) | 500 |
| UL Temperature Rating (°C) | 90 |
| Tongue Width (mm) | 48 |
| Finish/Coating | Tin-Plated |
| Product Type | Copper Compression Connectors - Lugs |
| Barrel Length (In.) | 2.88 |
| Tongue Angle | Straight |
| Tongue Width (In.) | 1.89 |
| Barrel Type | Long Barrel Length with Inspection Window |
| Tongue Thickness (mm) | 6.6 |
| Class G Copper Flex Conductor Size (kcmil) | 500 |
| Tongue Type | Standard |
| Stud Hole Size (mm) | 12.7 |
| Class I Copper Flex Conductor Size (kcmil) | 500 |
| Stud Hole Size (In.) | 1 to 2 |
| Class H Copper Flex Conductor Size (kcmil) | 500 |
| Overall Length (In.) | 5.03 |
| Panduit Die Index Number | P99 |
| Base Material | Copper |
| Product Class | Wire Termination |
| Package Quantity | 1 |
