Terminal de compresión de cobre, con 1 agujero, para cable de 500 kcmil, de 3/8 (9.5mm) de diámetro.
| Length | 1.2 in |
|---|---|
| Color Code | Brown |
| Overall Length | 2.32 in |
| Features | Corrosion Resistant, 90° Angled Connector |
| Stud Hole Size (In.) | 44,993 |
| Wire Strip Length (In.) | 1.81 |
| Barrel Length (mm) | 44.5 |
| Stud Hole Size (mm) | 9.5 |
| Tongue Angle | 90° |
| Maximum Voltage (kV) | 35 |
| Wire Strip Length (mm) | 46 |
| Finish/Coating | Tin-Plated |
| Tongue Thickness (In.) | 0.22 |
| Tongue Width (mm) | 39.1 |
| Panduit Die Index Number | P87 |
| Tongue Type | Standard |
| Barrel Type | Standard Barrel Length with Inspection Window |
| Overall Length (In.) | 2.32 |
| Tongue Width (In.) | 1.54 |
| Copper Code Conductor Size (kcmil) | 500 |
| Overall Length (mm) | 58.9 |
| UL Temperature Rating (°C) | 90 |
| Tongue Thickness (mm) | 5.6 |
| Product Type | Copper Compression Connectors - Lugs |
| Standards Met | C22.2 No. 65-13, 486A-486B File #E52164 |
| Barrel Length (In.) | 1-3/4 |
| Base Material | Copper |
| Burndy Die Index Number | 20 |
| Product Material | Copper |
| Connector Details | 1 x Terminal |
| Connector Plating | Tin |
| Product Name | Terminal Connector |
| Product Class | Wire Termination |
| Package Quantity | 1 |
