Terminal de compresión de cobre, 1 agujero, calibre #6 AWG F.
| Length | 1.3 in |
|---|---|
| Color Code | Blue |
| Overall Length | 1-1/4 in |
| Features | 90° Angled Connector, Corrosion Resistant |
| Copper Code Conductor Size (AWG) | 6 |
| Wire Strip Length (mm) | 14.3 |
| Burndy Die Index Number | 7 |
| Base Material | Copper |
| Tongue Type | Standard |
| Maximum Voltage (kV) | 35 |
| Class H Copper Flex Conductor Size (AWG) | 6 |
| Tongue Width (mm) | 15.7 |
| Tongue Thickness (mm) | 1.5 |
| Stud Hole Size (In.) | 44,993 |
| Panduit Die Index Number | P24 |
| Barrel Type | Standard Barrel Length with Inspection Window |
| Class I Copper Flex Conductor Size (AWG) | 6 |
| Stud Hole Size (mm) | 9.5 |
| Product Type | Copper Compression Connectors - Lugs |
| UL Temperature Rating (°C) | 90 |
| Class G Copper Flex Conductor Size (AWG) | 6 |
| Tongue Thickness (In.) | 0.06 |
| Class K Copper Flex Conductor Size (AWG) | 6 |
| Tongue Angle | 90° |
| Class M Copper Flex Conductor Size (AWG) | 6 |
| Tongue Width (In.) | 0.62 |
| Overall Length (mm) | 31.8 |
| Overall Length (In.) | 1-1/4 |
| DLO Copper Flex Conductor Size (AWG) | 6 |
| Barrel Length (mm) | 12.2 |
| Barrel Length (In.) | 0.48 |
| Finish/Coating | Tin-Plated |
| Product Name | Terminal Connector |
| Connector Details | 1 x Terminal |
| Connector Plating | Tin |
| Product Material | Copper |
| Product Class | Wire Termination |
| Package Quantity | 1 |
