Terminales de compresión de cobre, 1 orificio, 777.7 kcmil Flex, 5/8, LCAX750-58H-3
| Length | 4.2 in |
|---|---|
| Color Code | Yellow |
| Overall Length | 4.18 in |
| Features | 45° Angled Connector, Corrosion Resistant |
| Product Type | Copper Compression Connectors - Lugs |
| Tongue Thickness (In.) | 0.32 |
| UL Temperature Rating (°C) | 90 |
| Stud Hole Size (In.) | 45,054 |
| Overall Length (In.) | 4.18 |
| Wire Strip Length (In.) | 1.75 |
| Barrel Type | Standard Barrel Length with Inspection Window |
| Tongue Width (mm) | 55.1 |
| Finish/Coating | Tin-Plated |
| Maximum Voltage (kV) | 35 |
| Wire Strip Length (mm) | 44.5 |
| Stud Hole Size (mm) | 15.9 |
| Barrel Length (mm) | 42.2 |
| Panduit Die Index Number | P115 |
| Barrel Length (In.) | 1.66 |
| Tongue Thickness (mm) | 8.1 |
| Tongue Type | Standard |
| Overall Length (mm) | 106.2 |
| Base Material | Copper |
| Burndy Die Index Number | L115 |
| Tongue Angle | 45° |
| Tongue Width (In.) | 2.17 |
| Product Material | Copper |
| Connector Plating | Tin |
| Connector Details | 1 x Terminal |
| Product Name | Terminal Connector |
| Product Class | Wire Termination |
| Package Quantity | 1 |
