Terminal de compresión de cobre, de 2 orificios, calibre #1, con conector acampanado, modelo LCCF1-14B-X.
| Color Code | Pink |
|---|---|
| Overall Length | 3.31 in |
| Features | Corrosion Resistant, Flared Barrel |
| Wire Strip Length (mm) | 38.1 |
| Overall Length (mm) | 84.1 |
| Wire Strip Length (In.) | 1.5 |
| Tongue Width (In.) | 0.76 |
| Barrel Length (mm) | 36.6 |
| DLO Copper Flex Conductor Size (AWG) | 1 |
| Stud Hole Size (In.) | 44,930 |
| Finish/Coating | Tin-Plated |
| Maximum Voltage (kV) | 35 |
| Stud Hole Size (mm) | 6.4 |
| Base Material | Copper |
| Barrel Length (In.) | 1.44 |
| Tongue Thickness (In.) | 0.12 |
| Product Type | Compression Connectors - Lugs |
| Stud Hole Spacing (In.) | 0.75 |
| Class K Copper Flex Conductor Size (AWG) | 1 |
| Class M Copper Flex Conductor Size (AWG) | 1 |
| Tongue Type | Standard |
| Panduit Die Index Number | P42 |
| UL Temperature Rating (°C) | 90 |
| Overall Length (In.) | 3.31 |
| Tongue Thickness (mm) | 3 |
| Stud Hole Spacing (mm) | 19.1 |
| Tongue Width (mm) | 19.3 |
| Barrel Type | Long Barrel Length without Inspection Window |
| Connector Details | 1 x Terminal |
| Connector Plating | Tin |
| Product Name | Terminal Connector |
| Product Material | Copper |
| Product Class | Wire Termination |
| Package Quantity | 1 |
