Terminal de compresión de cobre, 2 orificios, #2 AWG, lengüeta estrecha, LCCXN2-14A-E.
| Color Code | Brown |
|---|---|
| Overall Length | 2.89 in |
| DLO Copper Flex Conductor Size (AWG) | 2 |
| Overall Length (In.) | 2.89 |
| Tongue Type | Narrow |
| Wire Strip Length (mm) | 36.5252 |
| Class I Copper Flex Conductor Size (AWG) | 2 |
| Base Material | Copper |
| Stud Hole Spacing (mm) | 16.002 |
| Tongue Angle | Straight |
| Copper Code Conductor Size (AWG) | 2 |
| Stud Hole Size (In.) | 44,930 |
| Tongue Thickness (mm) | 3.3 |
| Standards Met | UL Listed and CSA Certified, 90° C temperature rating when crimped with Panduit and specified competitor crimping tools and dies |
| Class K Copper Flex Conductor Size (AWG) | 2 |
| Panduit Die Index Number | P33 |
| Overall Length (mm) | 73.406 |
| Lug Type | 2 Stud Hole Lug |
| Maximum Voltage (kV) | 35 |
| Stud Hole Size (mm) | 6.35 |
| Barrel Type | Barrel with Inspection Window |
| Class G Copper Flex Conductor Size (AWG) | 2 |
| Barrel Length (mm) | 34.5 |
| Tongue Thickness (In.) | 0.13 |
| Class H Copper Flex Conductor Size (AWG) | 2 |
| Tongue Width (In.) | 0.47 |
| T & B Die Index Number | 33 |
| Tongue Width (mm) | 11.938 |
| Product Type | Compression Connectors - Lugs |
| Barrel Length (In.) | 1.36 |
| Class M Copper Flex Conductor Size (AWG) | 2 |
| Finish/Coating | Tinned |
| Wire Strip Length (In.) | 1.4375 |
| Stud Hole Spacing (In.) | 0.63 |
| Burndy Die Index Number | 10 |
| UL Temperature Rating (°C) | 90 |
| Product Class | Wire Termination |
| Package Quantity | 1 |
