Terminal de compresión de cobre, de 2 agujeros, calibre #8.
| Material | Copper |
|---|---|
| Color Code | Red |
| Tool Type | Tin-Plated Copper Compression Connectors - Lugs |
| Hole Center to Center | 44565 |
| Overall Length | 2.16 in |
| Standards | C22.2 No. 65-13, 486A-486B File #E52164 |
| Outside Dia. | 0.27 |
| Tongue Type | Standard |
| Barrel Type | Long Barrel without Inspection Window |
| Outer Diameter (In.) | 0.27 |
| Wire Strip Length (mm) | 19.1 |
| Tongue Width (In.) | 0.48 |
| Tongue Width (mm) | 12.2 |
| Overall Length (mm) | 54.9 |
| Outer Diameter (mm) | 6.85 |
| Lug Type | 2 Stud Hole Lug |
| UL Temperature Rating (°C) | 90 |
| Stud Hole Spacing (In.) | 0.63 |
| Stud Hole Spacing (mm) | 16 |
| Inside Diameter (In.) | 0.18 |
| Barrel Length (mm) | 17.8 |
| Stud Hole Size (In.) | 44,930 |
| Stud Hole Size (mm) | 6.4 |
| Panduit Die Index Number | P21 |
| Copper Code Conductor Size (AWG) | 8 |
| Wire Strip Length (In.) | 44,989 |
| Inside Diameter (mm) | 4.57 |
| Finish/Coating | Tin-Plated |
| Tongue Angle | Straight |
| Standards Met | C22.2 No. 65-13, 486A-486B File #E52164 |
| Barrel Length (In.) | 0.7 |
| Base Material | Copper |
| Product Type | Copper Compression Connectors - Lugs |
| Overall Length (In.) | 2.16 |
| Burndy Die Index Number | 49 |
| Tongue Thickness (In.) | 0.07 |
| Tongue Thickness (mm) | 1.8 |
| Maximum Voltage (kV) | 35 |
| Product Class | Lugs, Splices, Accessories, Split Bolts |
| Package Quantity | 1 |
