Terminal de compresión de cobre, 2 agujeros, barra larga
| Color Code | Yellow |
|---|---|
| Overall Length | 6.9 in |
| UL Temperature Rating (°C) | 90 |
| Product Type | Compression Connectors - Lugs |
| Lug Type | 2 Stud Hole Lug |
| Wire Strip Length (mm) | 77.8 |
| Tongue Width (In.) | 1-1/2 |
| Overall Length (mm) | 175.3 |
| Overall Length (In.) | 6.9 |
| Barrel Length (mm) | 76.2 |
| Stud Hole Spacing (In.) | 1.75 |
| Outer Diameter (In.) | 1.5 |
| Panduit Die Index Number | P115 |
| Maximum Voltage (kV) | 35 |
| Finish/Coating | Tin-Plated |
| Inside Diameter (mm) | 29.718 |
| Tongue Thickness (In.) | 0.32 |
| Standards Met | UL Listed for use in US and Canada to UL 486A-486B for power applications. |
| Base Material | Copper |
| Tongue Angle | Straight |
| Barrel Length (In.) | 3 |
| Barrel Type | Barrel with Inspection Window |
| T & B Die Index Number | 115 |
| Stud Hole Size (mm) | 12.7 |
| Outer Diameter (mm) | 38.1 |
| Burndy Die Index Number | L115 |
| Tongue Type | Narrow |
| Inside Diameter (In.) | 1.17 |
| Tongue Thickness (mm) | 8.128 |
| Tongue Width (mm) | 38.1 |
| Stud Hole Spacing (mm) | 44.45 |
| Stud Hole Size (In.) | 1 to 2 |
| Wire Strip Length (In.) | 3.06 |
| Outside Diameter Inches | 1-1/2 in |
| Product Class | Wire Termination |
| Package Quantity | 1 |
