Mechanical Connector, 250 Kcmil-10 AWG
| Item | Mechanical Connector,250 Kcmil-10 AWG |
|---|---|
| Insulation Material | PVC |
| Length | 3 in |
| Width | 2.6 in |
| Features | Double Sided |
| Height | 2.1 in |
| Overall Length | 2.97 in |
| Application | Aluminum or Copper Code Conductors |
| Maximum Aluminum Conductor Size (kcmil) | 250 |
| Base Material | Aluminum |
| Maximum Copper Conductor Size (kcmil) | 250 |
| Finish/Coating | Tin-Plated |
| Minimum Aluminum Conductor Size (AWG) | 10 |
| Overall Width (mm) | 66.8 |
| Standards Met | UL listed and CSA certified for use up to 600V & Temperature Rated to 90°C |
| Wire Strip Length (In.) | 0.88 |
| Overall Height (In.) | 2.13 |
| Overall Length (In.) | 2.97 |
| Overall Height (mm) | 54.1 |
| Product Type | Multi-Tap Mechanical Connectors, Double Sided |
| Wire Strip Length (mm) | 22.3 |
| UL Temperature Rating (°C) | 90 |
| Overall Length (mm) | 75.4 |
| Minimum Copper Conductor Size (AWG STR) | 10 |
| Number of Ports | 3 |
| Maximum Voltage (V) | 600 |
| Hex Size (mm) | 7.9 |
| Overall Width (In.) | 2.63 |
| Note | PCSB250-3-6Y replaces PCSB250-3-6 |
| Product Material | Polyvinyl Chloride |
| Product Name | Pan-Lug Terminal Connector |
| Product Color | Clear |
| Product Line | Pan-Lug |
| Connector Details | Multi-tap Terminal |
| Product Class | Mechanical Lugs |
| Package Quantity | 1 |
