Mechanical Connector, 250 Kcmil-10 AWG
| Item | Mechanical Connector,250 Kcmil-10 AWG |
|---|---|
| Insulation Material | PVC |
| Length | 3.9 in |
| Width | 2.6 in |
| Height | 2.1 in |
| Application | Aluminum or Copper Code Conductors |
| Features | Double Sided |
| Overall Length | 3.91 in |
| Overall Width (mm) | 66.8 |
| Number of Ports | 4 |
| Product Type | Multi-Tap Mechanical Connectors, Double Sided |
| Note | PCSB250-4-6Y replaces PCSB250-4-6 |
| Overall Height (In.) | 2.1 |
| Overall Height (mm) | 54.1 |
| UL Temperature Rating (°C) | 90 |
| Overall Width (In.) | 2.63 |
| Overall Length (In.) | 3.91 |
| Base Material | Aluminum |
| Maximum Voltage (V) | 600 |
| Overall Length (mm) | 99.3 |
| Connector Details | Multi-tap Terminal |
| Product Material | Polyvinyl Chloride |
| Product Line | Pan-Lug |
| Product Name | Pan-Lug Terminal Connector |
| Product Color | Clear |
| Product Class | Mechanical Lugs |
| Package Quantity | 1 |
