Mechanical Connector, 350 Kcmil-10 AWG
| Item | Mechanical Connector,350 Kcmil-10 AWG |
|---|---|
| Insulation Material | PVC |
| Length | 4.2 in |
| Width | 3 in |
| Application | Aluminum or Copper Code Conductors |
| Overall Length | 4.17 in |
| Features | Double Sided |
| Height | 2-1/2 in |
| Overall Height (In.) | 2-1/2 |
| Number of Ports | 4 |
| Product Type | Multi-Tap Mechanical Connectors, Double Sided |
| Overall Height (mm) | 63.5 |
| Overall Width (In.) | 3 |
| Overall Width (mm) | 76.2 |
| Overall Length (In.) | 4.17 |
| Overall Length (mm) | 105.9 |
| UL Temperature Rating (°C) | 90 |
| Maximum Voltage (V) | 600 |
| Base Material | Aluminum |
| Product Material | Polyvinyl Chloride |
| Connector Details | Multi-tap Terminal |
| Product Color | Clear |
| Product Line | Pan-Lug |
| Product Name | Pan-Lug Terminal Connector |
| Product Class | Wire Termination |
| Package Quantity | 1 |
