Multi-Tap Connector, 1/0 AWG-14 AWG
| Item | Multi-Tap Connector,1/0 AWG-14 AWG |
|---|---|
| Width | 0.95 in |
| Minimum Copper Conductor Size (AWG SOL) | 10 |
| Minimum Copper Conductor Size (AWG STR) | 14 |
| Maximum Copper Conductor Size (AWG SOL) | 8 |
| Maximum Copper Conductor Size (AWG STR) | 36,526 |
| UL Temperature Rating (°C) | 90 |
| Insulation Type | Clear PVC |
| Overall Length (mm) | 73.9 |
| Overall Width (In.) | 0.95 |
| Base Material | Aluminum |
| Product Type | Connector, Reducer, In-Line Splicer |
| Hex Size (mm) | 4.78 |
| Overall Length (In.) | 2.91 |
| Overall Height (mm) | 35.8 |
| Maximum Voltage (V) | 600 |
| Maximum Aluminum Conductor Size (AWG) | 36,526 |
| Wire Strip Length (In.) | 0.94 |
| Overall Width (mm) | 24.1 |
| Minimum Aluminum Conductor Size (AWG) | 14 |
| Wire Strip Length (mm) | 23.9 |
| Standards Met | UL Listed and CSA Certified for use up to 600 V |
| Overall Height (In.) | 1.4 |
| Product Class | Splices |
| Overall Length | 2.91 in |
| Height | 1.4 in |
| Package Quantity | 1 |
