Multi-Tap Connector, 250 Kcmil-10 AWG
| Item | Multi-Tap Connector,250 Kcmil-10 AWG |
|---|---|
| Insulation Material | Vinyl |
| Width | 1-1/4 in |
| Minimum Copper Conductor Size (AWG STR) | 10 |
| Product Type | Connector, Reducer, In-Line Splicer |
| Maximum Copper Conductor Size (kcmil) | 250 |
| Overall Width (mm) | 31.75 |
| Maximum Voltage (V) | 600 |
| Standards Met | UL listed and CSA certified for use up to 600V & Temperature Rated to 90°C |
| Hex Size (mm) | 7.93 |
| Minimum Copper Conductor Size (AWG SOL) | 10 |
| Overall Width (In.) | 1-1/4 |
| Wire Strip Length (In.) | 1.12 |
| UL Temperature Rating (°C) | 90 |
| Wire Strip Length (mm) | 28.5 |
| Minimum Aluminum Conductor Size (AWG) | 10 |
| Finish/Coating | Tin-Plated |
| Overall Length (mm) | 101.6 |
| Overall Height (mm) | 56.9 |
| Maximum Aluminum Conductor Size (kcmil) | 250 |
| Barrel Length (In.) | 4 |
| Overall Height (In.) | 2.24 |
| Overall Length (In.) | 4 |
| Barrel Length (mm) | 101.6 |
| Base Material | Aluminum |
| Barrel Type | Standard |
| Maximum Copper Conductor Size (AWG SOL) | 8 |
| Overall Length | 4 in |
| Product Class | Splices |
| Height | 2.2 in |
| Package Quantity | 1 |
