ThermTrans, 2-Sided Heatshrink Tubing, M
| Material | Polyolefin |
|---|---|
| Color | White |
| Features | Double Sided |
| Width | 1 in |
| Height | 0.34 in |
| Resistance Properties | Military Grade |
| Number of Labels | 5 |
| Number of Sides | 2 |
| Minimum Cable Diameter (mm) | 1.5 |
| Number of Labels per Row | 2 |
| Diameter (In.) | 0.19 |
| Label Property | Flammability, Fluid Resistance, Harsh Environments, Military Grade |
| Label Application | Cable & Wire Marking |
| Printer Type | Thermal Transfer |
| Flammability Rating | VW-1 |
| Maximum Cable Diameter (In.) | 0.19 |
| Maximum Operating Temperature (°C) | 135 |
| Minimum Operating Temperature (°C) | -55 |
| Overall Width (In.) | 1 |
| Diameter (mm) | 4.8 |
| Overall Width (mm) | 25.4 |
| Minimum Cable Diameter (In.) | 0.06 |
| Product Type | Heat Shrink Label |
| Minimum Operating Temperature (°F) | -67 |
| Compatible Wire Gauge (AWG) | 18-12 |
| Maximum Cable Diameter (mm) | 4.8 |
| Overall Height (In.) | 0.34 |
| Maximum Operating Temperature (°F) | 275 |
| Overall Height (mm) | 8.6 |
| Label Height | 11/32 in |
| Number of Labels per Roll | 5,000 |
| Print Technology | Thermal Transfer |
| Product Color | White |
| Product Material | Polyolefin |
| Label Width | 1 in |
| Label Diameter | 3/16 in |
| Product Name | Cable Label, Wire |
| Product Class | Signs, Labels & Identification |
| Max Operating Temperature | 135 degrees Celsius |
| Diameter | 4.7 mm |
| Min Operating Temperature | -55 degrees Celsius |
| Package Quantity | 1 |
