ThermTrans, 2-Sided Heatshrink Tubing, M
| Material | Polyolefin |
|---|---|
| Color | Yellow |
| Features | Double Sided |
| Width | 2 in |
| Overall Length | 0.84 in |
| Height | 0.84 in |
| Compatible Wire Gauge (AWG) | 45139 |
| Minimum Operating Temperature (°F) | -67 |
| Flammability Rating | VW-1 |
| Overall Height (In.) | 0.84 |
| Minimum Cable Diameter (In.) | 0.17 |
| Maximum Cable Diameter (In.) | 0.5 |
| Overall Width (mm) | 50.8 |
| Minimum Operating Temperature (°C) | -55 |
| Maximum Cable Diameter (mm) | 12.7 |
| Diameter (In.) | 0.5 |
| Diameter (mm) | 12.7 |
| Label Property | Flammability, Fluid Resistance, Harsh Environments, Military Grade |
| Overall Height (mm) | 21.3 |
| Overall Width (In.) | 2 |
| Number of Labels per Row | 1 |
| Number of Labels | 500 |
| Product Type | Heat Shrink Label |
| Printer Type | Thermal Transfer |
| Maximum Operating Temperature (°C) | 135 |
| Maximum Operating Temperature (°F) | 275 |
| Number of Sides | 2 |
| Minimum Cable Diameter (mm) | 4.3 |
| Label Application | Cable & Wire Marking |
| Resistance Properties | Military Grade |
| Printable | Yes |
| Product Name | Cable Label, Wire |
| Label Diameter | 1/2 in |
| Print Technology | Thermal Transfer |
| Label Width | 2 in |
| Label Height | 27/32 in |
| Product Color | Yellow |
| Number of Labels per Roll | 500 |
| Label Length | 27/32 in |
| Product Material | Polyolefin |
| Min Operating Temperature | -55 degrees celsius |
| Max Operating Temperature | 135 degrees celsius |
| Product Class | Signs, Labels & Identification |
| Diameter | 12.7 mm |
| Package Quantity | 1 |
